Each of the setting values for the paper type, print mode, and output profile as well as the adjustment values con-
figured in the Color Settings sheet (color or monochrome) are printed at the bottom of the paper. However, the
adjustment values for the Curve are not printed.
•
The job name when printing the adjustment pattern is "Original Image Name + Pattern-Print". For example, the print job
name for the image "ABC.jpg" is "ABC_Pattern-Print.jpg".
Note
• Maximize Dialog Box button
When this button is clicked, the Adjustment pattern setting dialog box is displayed enlarged to cover the entire
display screen.

Paper Detailed Settings Dialog Box

Paper Detailed Settings Dialog Box

This dialog box appears when you click the Advanced Settings button on the Main Sheet. You can set Drying Time
and Roll Paper Margin for Safety by media type.
• Roll Paper Margin for Safety
Near End Margin
This sets the length of the near end margin of the roll paper.
Setting
Printer Default
5mm
20mm
• Cut Speed
This selects the auto cut speed.
Setting
Printer Default
Fast
Standard
User's Guide
The settings of the printer operating panel are applied.
Print at a standard size.
*Select for Media Type that has no problem when printing with a standard size margin.
Select this when rubbing against the printhead occurs such as when using paper that tends to
curl.
The settings of the printer operating panel are applied.
Select this setting if cutting with the Standard setting is not clean.
Select this setting when you are not experiencing problems.
