- Page 1 Installation Instructions Thermal Print- head for EasyCoder F4 and EasyCoder F4 Compact Industrial...
- Page 2 © Copyright Intermec Printer AB, 2002. All rights reserved. Published in Sweden. EasyCoder, EasyLAN, Fingerprint, and LabelShop are registered trademarks of Intermec Tech- nologies Corp. The word Intermec, the Intermec logo, InterDriver, PrintSet, and Duratherm are trademarks of Intermec Technologies Corp.
- Page 3 Printhead for EasyCoder F4 & F4 Compact Industrial, Installation Instructions EasyCoder F4-Series—Printhead Replacement The EasyCoder F4 and F4 Compact Industrial are fi tted with8 dots/mm high-performance thermal printheads. When the media is fed past the printhead, small resistor elements (dots) on the printhead are electrically charged and thereby heated.
- Page 4 If the printer is fi tted with an optional printhead spring (EasyCoder F4 only), the spring must be removed to allow the printhead to be pulled out and refi tted after the replacement printhead has been installed.
- Page 5 Step-by-Step Instructions Open the side door. Remove the media and transfer ribbon. Printhead for EasyCoder F4 & F4 Compact Industrial, Installation Instructions EasyCoder F4-Series—Printhead Replacement Turn the printhead lift lever clockwise to raise the printhead. Pull the printhead bracket away from the magnet in...
- Page 6 Connect the two cables to the replacement printhead. Printhead for EasyCoder F4 & F4 Compact Industrial, Installation Instructions Disconnect the cables from the printhead. Note the snap-lock on the inner connector. Pull at the connec- tors–not at the cables!
- Page 7 Step-by-Step Instructions, cont. Turn the printhead lift lever counterclockwise so the Load a new supply of media and ribbon, as described magnet engages the printhead bracket. in the User’s Guide Printhead for EasyCoder F4 & F4 Compact Industrial, Installation Instructions...
- Page 8 Intermec Printer AB Idrottsvägen 10, P.O. Box 123 S-431 22 Mölndal, Sweden tel +46 31 869500 fax +46 31 869595 www.intermec.com Thermal Printhead for EasyCoder F4 & F4 Compact Industrial, Installation Instructions *1-960479-02* *1-960479-02*...
