Chapter 7 Setting Up the Printer
Setup Parameters, cont.
Print Defi nes, cont.
58

Print Speed

The print speed is variable between 100 and 200 mm/sec. Generally,
the lower the speed, the better the printout quality. This is especially
true when printing bar codes with the bars running across the media
path ("ladder style"), when printing on demanding face materials,
and when printing at low ambient temperatures. Refer to the tables
under "Media" earlier in this chapter for maximum print speed
values. The default setting is 100 mm/sec. ( 4 inches/sec.).
The combination of a larger media roll (>152 mm/6 inches
diameter) and/or narrow media width in combination with high
print speed (> 150 mm/6 inches per sec.) could cause jerks
in the media feed. Such jerks will compress text and spoil the
readability of ladder-style bar codes placed close to the front
edge of the label. In case of batch printing, only the fi rst label
in the batch will be affected. Negative startadjust values tend
to increase the jerks.
• If the media roll is larger than 152 mm (6 inches), do not use
a print speed > 150 mm/s.
• If a negative start adjust is used, do not use a print speed
> 125 mm/s.
• Narrow media width may require further restrictions on print
speed.
• Avoid placing text and ladder-style bar codes close to the
front edge of labels.
Intermec EasyCoder F4 – Installation & Operation Ed. 3
Caution!
