- Page 1 Installation Instruc- tions EasyCoder F4 Cutter...
- Page 2 © Copyright Intermec Printer AB 2002. All rights reserved. Published in Sweden. EasyCoder, EasyLAN, Fingerprint, and LabelShop are registered trademarks of Intermec Technologies Corp. The word Intermec, the Intermec logo, InterDriver, and PrintSet are trademarks of Intermec Tech- nologies Corp.
- Page 3 Avoid cutting soft plastic-based media. Minimum media thickness: 78µm Maximum media thickness: 175µm When a cutter is installed, the measures of the EasyCoder F4 are increased as follows (tray not included): Measurement Increase Length: 50 mm (1.97 in) Width: 9 mm (0.35 in)
-
Page 4: Installation
Chapter 2 The EasyCoder F4 Cutter is easy to install and requires no Installation modifi cation of the printer itself. The installation kit contains: - Cutter unit (1) - Tray (1) - Cable (1) - Cable cover (1) - #T20 Torx screws and washers (3) - Installation Instructions (1) The only tool required is a #T20 Torx screwdriver. - Page 5 (thermal transfer model only). Connect the cable to P42 at the top/front corner of the CPU board (marked “console”). Intermec EasyCoder F4 Cutter – Installation Instructions Ed. 3...
-
Page 6: Operation
Stop adjust ........: + 160 Cut variable length strip (no liner!) Start adjust ........: - 250 Stop adjust ........: + 275 Refer to the printer’s User’s Guide for media load instructions. Media Load Intermec EasyCoder F4 Cutter – Installation Instructions Ed. 3... - Page 8 Intermec Printer AB Idrottsvägen 10, P.O. Box 123 S-431 22 Mölndal, Sweden tel +46 31 869500 fax +46 31 869595 www.intermec.com EasyCoder F4 Cutter — Installation Instructions *1-960492-02* *1-960492-02*...
