Appendix 4

EasySet Bar Code Wand Setup

Connection and Operation
1. Connect the optional EasySet bar code wand to
the receptacle on the printer's rear plate.
3. When the bar code has been accepted, the printer
emits a short beep and the "Ready" control lamp
on the printer's front blinks briefl y.
112
2. Read the appropriate bar code to set up the
printer. Hold the wand like a pencil and move it
swiftly across the bar code.
Connect
here!
4. This manual only contains a selection of setup
options. For information on how to produce your
own setup bar codes, please refer to the Intermec
Fingerprint v7.xx, Reference Manual.
Intermec EasyCoder F4 – Installation & Operation Ed. 3
