3-26 RAID Array 3000 Controller Shelf Hardware User's Guide

Replacing Field Replaceable Units (FRUs)

This section describes how to replace an FRU in the controller shelf. The

information is divided into the following subsections:

Replacing a Host I/O or Device I/O SBB in the controller shelf

Replacing a shelf power supply SBB

Replacing the RAID controller

Replacing the UPS

Replacing a blower.

Replacing a controller memory cache module

NOTE: The rack-mount UPS is also field replaceable. Refer to the user's guide supplied

with the unit for the order number and instructions of how to replace it.
