4-4 RAID Array 3000 Controller Shelf Hardware User's Guide

Updating Firmware

A Save Configuration dialog box appears as shown in Figure 4-2. The
example in Figure 4-2 shows the Save to File name as c:\config1.
1. Type your file name and click Save.

Figure 4-2. Save Configuration dialog box

CAUTION: If the systems disk is on the RA3000, firmware cannot be upgraded
with SWCC. Establish a temporary system disk on a disk drive outside the
RA3000 and proceed with these instructions or follow the alternative shown in
" Updating Firmware Using Serial Interface" .
Updating Firmware Using SWCC
Start SWCC and choose SCSI or Network Connection. From the Storage
menu, click Controller, and then click Update Firmware (see Figure 4-3).

Figure 4-3. Update firmware command
