Table 1-3 Single Host, Single Adapter, With Two Active Controllers - Compaq StorageWorks RAID Array 3000 Controller Shelf User Manual

1-18 RAID Array 3000 Controller Shelf Hardware User's Guide
Figure 1-10 shows a diagram of a Single Host, Single Adapter, with two
Active Controllers.
2
Host
System
Host
Adapter
Figure 1-10. Single host, single adapter, with two active controllers
Single Host, Single Adapter, with Two Active Controllers
Item #
å
Device expansion shelves

Host-In connector on H0 I/O module
ê
Controller shelf
‚
SCSI cable BN37A-05 (host adapter connection made using technology
adapter cable BN38E-OB, not shown)
ƒ
SCSI cable BN37A-OE combining host modules H0 and H1
ñ
Host-In connector on H0 I/O module
ò
Host-In connector on H1 I/O module
ô
H1 host I/O module Host-Out connector (not used in this configuration)
õ
SCSI cables BN37A-OE (2) for device I/O module 0
ù
SCSI cables BN37A-OE (2) for device I/O module 1
shr-1317b
Table 1-3
Description
