Installing Shelf Supports

After you determine the desired shelf slot locations in your cabinet, install the
shelf support mounting kits supplied with the shelves. Shelf support mounting
kits for the RETMA and metric style cabinets are included with each shelf
assembly. The UPS is rack mounted using custom adjustable rail brackets.
Table 3–1 lists the shelf support mounting kits and identifies the documents
and procedures that contain the instructions needed to install them.
Cabinet Style
RETMA cabinet installation
(round hole).
RETMA cabinet installation
(square hole).
Metric cabinet
Installation
UPS installation into a
RETMA or metric
cabinet
Shelf Support Mounting Kits and Installation Guides
Shelf Support Kit
Part No.
70-33381-01
70-33381-01
BA35X-RD
74-53154-01/02
(plus hardware)
Installation and Maintenance 3-7
Table 3-1
Installation Guide/Part No.
"
See Installing Shelf Supports in a
RETMA Cabinet (Round Hole)
"
See Installing Shelf Supports in a
RETMA Cabinet (Square Hole)
SW500 and SW800 Cabinet Metric
Shelf Bracket Kit Installation Guide
"
See

Installing UPS Brackets

"
"
"
