1-16 RAID Array 3000 Controller Shelf Hardware User's Guide
Connecting the Controller Shelf to a Host
System
This section shows how to connect four possible controller shelf/host
configurations. The configurations are:
Single host, single adapter, with one active controller
Single host, single adapter, with two active controllers
Single host, dual adapter, two ports with two active controllers
Dual host, single adapter, with one active controller per host
