Getting Started with Your SpectraLink 8020/8030 Wireless Telephone
1. Earpiece —Delivers audio to the ear.
2. Screen —Displays information relating to the handset's current
mode. See Handset Modes below.
3. Softkeys —Four softkey buttons. A softkey label appears in the
display area just above the corresponding softkey when the
function assigned to that softkey is available.
4. Headset jack —Allows you to place and receive calls through a
SpectraLink headset.
5. Up/Down buttons —Use these buttons to scroll through displayed
menu options. Use to adjust speaker volume while in a call.
6. Emergency Dial/TALK button —SpectraLink 8030 only. This button
may be programmed by the system administrator for either
Emergency Dial or Push-to-talk (PTT) functionality. Test the
active mode by pressing the button once to see which feature is
active. If you are prompted to press it twice to place an emergency
call, then Emergency Dial is programmed. Check the
to determine if PTT is activated. Push and hold to activate push-
to-talk mode.
7. On hook —Also referred to as
the handset, and to end a call.
8. Off hook —Also referred to as
place a call.
9. Nav and Nav OK keys —Four directional navigation keys and a
key. Use the Nav
NavOK
Use the key to select menu items, place calls, and perform
NavOK
softkey functions as described below in NavOK functions.
10. Keypad —12 keys provide the 10 digits 0-9, the alphabetic
characters, and special characters available in context-sensitive
applications.
11. FCN —Press to access the Function menu; press in combination
with assigned keys to access programmed system functions.
12. LINE —Press to access additional line appearances.
13. Battery contacts —Located along the bottom edge, the battery
contacts enable the handset to be charged in the Desktop Charger
or the Dual Charger. They should be kept clean and free of debris.
14. Microphone —Sensitive microphone transmits voice accurately
and without distortion.
. Use to power on and power off
END
. Use to obtain a dial tone or
START
and keys for menu navigation.
menu
Config
