Rear panel

9
10 11 12 13 14 15
1. GROUND: You may directly connect the signal
grounds of other equipment tot the signal ground
of the Project Two.
2. TAPE OUT: Connect this output to the input of
the recorder.
3. TAPE IN: Connect this input to the output of the
recorder.
4. CD: To connect the cinch signal cable from the
CD player.
5. TUNER: To connect the cinch signal cable from
the tuner.
6. LINE 1: To connect the cinch signal cable from
the signal source for LINE 1.
7. LINE 2: To connect the cinch signal cable from
the signal source for LINE 2.
8. LINE 3: To connect the cinch signal cable from
the signal source for LINE 3.
9. CD BALANCED L: To connect the XLR signal
cable (balanced cable) from the left output of the
CD player.
10. CD BALANCED R: To connect the XLR signal
cable (balanced cable) from the right output of
the CD player.
SPHINX
16
17
18
19
11. BALANCED OUT L: To connect the XLR signal
12. BALANCED OUT R: To connect the XLR signal
13. OUT 1 L+R: Connect this output with a cinch
14. OUT 2 L+R: To connect the XLR signal cable
15. Control Out: To connect the optical cable going
16. Warning!: This shows important information
17. AC Power: Connect the mains cable to a mains
18. O / I: This is the mains power switch.
19. Fuse holder: Contains a fuse.
20. Selector for power supply voltage (120/240 V),
Project Two Mk2
20
21 22 23
24
cable (balanced cable) from the left input of the
power amp.
cable (balanced cable) from the right input of the
power amp.
signal cable to the input of your power amp.
(balanced cable) from the right input of the extra
power amp or surround processor.
to another Sphinx component.
about the safety regulations of the Project Two
MK2.
power outlet (100 - 240 VAC).
(115/230 V).
25
26 27 28
5
