SPHINX Myth 11

Rear panel

Warning!
!
Do not open!
High voltage inside!
Do not expose this unit
to rain or moisture.
OUTPUT R
1
1. Warning label: This shows important safety
warnings.
2. OUTPUT R: To connect the cable from the right
loudspeaker:
red +
black -
3. CONTROL IN: To connect the optical cable from
another Sphinx component like a pre-amp.
4. INPUT: To connect the cinch cables from the
output of the signal source.
INPUT
CONTROL
IN
4
2 3
Service Manual
AC Voltage: 220V/60Hz.
Fuse: 3,15 AT
L
Max. Power: 600 W
Made in The Netherlands
Manufactured by :
R
Sphinx Laboratories
5
5. Manufacturer's label: This shows important
data for the component, such as serial number
and mains power voltage.
6. OUTPUT L: To connect the cable from the left
loudspeaker:
red
black
7. AC POWER: Connect the power amp to a
mains outlet (230 - 240 VAC) and the mains
power switch.
The mains fuse is placed behind the cover.
OUTPUT L
6 7
+
-
5
