3. THE PRE-AMP AT A GLANCE

Front panel

1
1. INPUT: With this rotary knob you select one of
the six inputs. Turn clockwise for an input to the
right of the active one, anti-clockwise for an input
to the left.
2. STANDBY: To switch the component on and off:
on LED is green
off LED is red
3. Receptor window for the IR signals from the
Remote Control.
4. Input selection LED's: The input selected with
knob (1.) is indicated by one of these LED's:
CD SYM balanced CD input
CD unbalanced CD input
TUNER Tuner
LINE 1 unbalanced line input 1
LINE 2 unbalanced line input 2
LINE 3 unbalanced line input 3.
SPHINX
3
2 4
5. MUTE: Press this button to temporarily mute the
6. TAPE MON: To select the TAPE IN input. The
7. PHONES: To connect dynamic stereo
8. VOLUME: This rotary knob adjusts the volume
Project Two Mk2
6 7
sound. The red LED will light.
red LED will light.
headphones.
level.
8
4
