Battery Pack; Chargers; Belt Clips; Dc Cables - Icom IC-41S Instruction Manual

D

BATTERY PACK

Battery pack Voltage
BP-232N 7.4 V
Battery case for AAA
BP-240
(LR03) × 6 alkaline
1
* When the power save function is turned ON, and the operating
periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
2
* Operating period depends on the alkaline cells used.
D

CHARGERS

• BC-119N + AD-106
DESKTOP CHARGER
+ BC-145SV
AC ADAPTER
For rapid charging of battery packs. An AC adapter is supplied with
the charger.
Charging time: approx. 3 hours when BP-232N is attached.
• BC-121N - + AD-106
MULTI CHARGER
+ BC-157S
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-106's are required)
simultaneously. An AC adapter should be purchased separately.
Charging time: approx. 3 hours when BP-232N is attached.
• BC-160 + BC-145SV
DESKTOP CHARGER
For rapid charging of battery packs. An AC adapter is supplied with
the charger.
Charging time: approx. 3 hours when BP-232N is attached.
1
Capacity Battery life*
2000 mAh 13.5 hrs.
2
—*
CHARGER ADAPTER
(6 pcs.)
CHARGER ADAPTER
AC ADAPTER
D

BELT CLIPS

• MB-93
SWIVEL BELT CLIP
• MB-94
BELT CLIP
Exclusive alligator-type belt clip.
• MB-96N/96F
LEATHER BELT HANGER
D

DC CABLES

• CP-23L
CIGARETTE LIGHTER CABLE
Allows charging of the battery pack through a 12 V cigarette lighter
socket. (For BC-119N/BC-160)
• OPC-515L/OPC-656
DC POWER CABLES
Allows charging of the battery pack using a 13.8 V power source
instead of the AC adapter.
OPC-515L : For BC-119N/BC-160
OPC-656 : For BC-121N
11
OPTIONS
