Disconnect Mode Option
Disconnect with DTR drop
Ignore DTRa
Telnet mode and terminal type setup
Channel (port) password
Hard disconnect
Disable hard disconnect
State LED off with connection
Disconnect with EOT (^D)
1. The SDS will send the "Terminal Type" upon an outgoing connection.
2. A password is required for a connection to the serial port from the network.
3. The TCP connection will close even if the remote site does not acknowledge
the disconnection.
4. When there is a network connection to or from the serial port, the state LED
will turn off instead of blink.
5. When Ctrl D or Hex 04 are detected, the connection is dropped. Both Telnet
mode and Disconnect with EOT must be enabled for Disconnect with EOT to
function properly. Ctrl D will only be detected going from the serial port to
the network.

Flush Mode (Buffer Flushing)

Using this parameter, you can control line handling and network buffers with
connection startup and disconnect. You can also select between two different
packing algorithms.
Note:
yourself, look up the values in
to Hexadecimal chapter.
Function
Input Buffer (Serial to Network)
Clear with active connection (from serial)
Clear with passive connection (from network)
Clear with disconnect
Output Buffer (Network to Serial)
Clear with active connection (from serial)
Clear with passive connection (from network)
Clear with disconnect
Alternate Packing Algorithm (Pack Control)
Enable

Pack Control

Two firmware-selectable packing algorithms define how and when packets are sent
to the network. The standard algorithm is optimized for applications in which the unit
is used in a local environment, allowing for very small delays for single characters
while keeping the packet count low. The alternate packing algorithm minimizes the
If you do not want to convert the binary numbers to hexadecimals yourself,
Table 6-4. Disconnect Mode Options
Table 3-9. Disconnect Mode Options
2
3
5
If you do not want to convert the binary numbers to hexadecimals
Table 3-10. Flush Mode Options
Bit 7 6 5 4 3 2 1 0
1
0
1
1
1
4
1
Table 6-5. Flush Mode Options
Bit 7 6 5 4 3 2 1 0
1
1
41
