3: Configuring the Unit

You must configure the unit so that it can communicate on a network with your serial
device. For example, you must set the way the unit will respond to serial and network
traffic, how it will handle serial packets, and when to start or close a connection. You
can configure your unit locally or remotely using the following procedures:
The unit's configuration is stored in nonvolatile memory (NVRam) and is retained
without power. You can change the configuration at any time. The unit performs a
reset after the configuration has been changed and stored.

Configuring via Web Browser

If your unit already has an IP address, you can log into it using a standard Web
browser with Java enabled.
1. Type the unit's IP address into the Web browser's URL (Address/Location) field.
2. When the SDS Configuration Guidelines Page appears, select one of the four
links:
Use a standard Web browser to access the unit's internal Web pages and
configure the unit over the network. This is the easiest and preferred method.
Use a Telnet connection to configure the unit over the network.
Use a terminal or terminal emulation program to access the serial port
locally.
Figure 3-1. Web Browser Login
27
