SDS1100 User Guide

Methods of Assigning the IP Address

The unit's IP address must be configured before a network connection is available.
You have the following options for assigning an IP to your unit:
Method Description
DHCP A DHCP server automatically assigns the IP address and network settings.
DeviceInstaller You manually assign the IP address using a graphical user interface (GUI).
You must use a PC and the unit must be attached to the local network.
ARP and You manually assign the IP address and other network settings at a command
Telnet prompt using a UNIX or Windows-based system. Only one person at a time can
be logged into the configuration port (port 9999). This eliminates the possibility of
several people simultaneously attempting to configure the unit.
AutoIP This automatic method is appropriate when you have a small group of hosts rather
than a large network. This method allows the hosts to negotiate with each other
and assign addresses, in effect creating a small network.
Serial Port You initially configure the unit through a serial connection.
Login
These methods are described in the remaining sections of this chapter.
Note: In most installations, a fixed IP address is desirable. The systems
administrator generally provides the IP address. Obtain the following
information before starting to set up your unit:
IP Address
Subnet Mask: ___ ___ ___ ___
Gateway:
___ ___ ___ ___
___ ___ ___ ___
18
2: Getting Started
