SDS1100 User Guide

DeviceInstaller

You can manually assign the IP address using the DeviceInstaller, which is on the
product CD.

Install the DeviceInstaller

1. Insert the product CD into your CD-ROM drive. The Lantronix SDS1100
DeviceServer window displays.
2. If the CD does not launch automatically:
3. Click the Start button on the Task Bar and select Run.
4. Enter your CD drive letter, colon, backslash, deviceinstaller.exe (e.g.,
E:\deviceinstaller.exe).
5. Click the DeviceInstaller button. The installation wizard window displays.
6. Respond to the installation wizard prompts. (When prompted to select an
installation type, select Typical.)

Assign IP Address and Network Class

1. Click the Start button on the Task Bar and select Programs
Device Installer Device Installer. The DeviceInstaller window displays.
Figure 2-3. DeviceInstaller Window
20
2: Getting Started
Lantronix
