AC Power

Power over Ethernet

Power over Ethernet is the default connection for your phone.
Note AC power adapters are not included in the PoE package. If you require one, see
your system administrator.
The following figure shows how to connect your phone to the network using
a PoE source.
1
To connect the phone using a PoE source:
Connect one end of the 25-foot Network Cable to the LAN jack on the
1.
phone.
Connect the other end of the 25-foot Network Cable to an available LAN
2.
port on the wall or hub/switch device port.
AC Power
To connect your phone to the network using AC power, make sure you have
the optional AC Power Kit. The AC Power Kit contains a Power Adapter,
Regional Power Cord, and a Power Insertion Cable.
2
25-foot Network Cable
1 - 3
