1

Registering the Phone

The following figure shows how to connect your phone to the network using
optional AC power.
25-foot Network Cable
To connect the phone using AC power:
Connect one end of the 25-foot Network Cable to the LAN jack on the
1.
phone.
Connect the other end of the 25-foot Network Cable to the
2.
Power Insertion Cable.
Connect the Power Insertion Cable to an available LAN port on the wall
3.
or hub/switch device port.
4. Connect the Power Adapter to the Power Insertion Cable.
Connect the Power Adapter (with the attached Regional Power Cord) to
5.
the wall outlet.
Generally, your phone will be deployed with multiple other phones. In this
case, your system administrator will configure the phone parameters
beforehand, so that after you set up your phone, the phone will be registered
and ready to use.
Power Insertion Cable
2
4
Power Adapter
3
5
1 - 4
