Throttle twistgrip

(fig. 97)
The twistgrip (1, fig. 97) on the right handlebar opens the
throttles. When released, it will spring back to the initial
position (idling speed).

Front brake lever

(fig. 98)
Pull the lever (1, fig. 98) towards the twistgrip to operate the
front brake. The system is hydraulically assisted and you only
need to pull the lever gently.
The control lever (1, fig. 98) features a dial adjuster (2, fig. 98)
for lever distance from the twistgrip on semihandlebar
adjustment.
The lever distance can be adjusted through 10 clicks of the
dial (2, fig. 98). Turn clockwise to increase lever distance
from the twistgrip. Turn the adjuster counter clockwise to
decrease lever distance.
1
E
fig. 97
fig. 98
115
