I Offset frequency
When communicating through a repeater, the transmit frequency is
shifted from the receive frequency by an amount determined by the

offset frequency.

q
Push [A•
FUNC
w
Push [Y]/[Z] several times until "±" and
offset frequency appear.
e
Rotate [VOL] to select the desired offset
frequency.
• Selectable steps are the same as the pre-set tuning steps.
• The unit of the displayed offset frequency is "MHz."
r
Push [#•
ENT
I Subaudible tones
Some repeaters require subaudible tones to be accessed. Sub-
audible tones are superimposed over your normal signal and must
be set in advance.
q
Push [A•
FUNC
.
SET MODE
w
Push [Y]/[Z] one or more times until "rt"
appears.
e
Rotate [VOL] to select the desired subaudible tone.
r
Push [#•
ENT
Available subaudible tone frequencies
67.0 79.7
69.3 82.5
71.9 85.4
74.4 88.5
77.0 91.5
], then push [8•
] to fix the offset frequency and exit
], then push [8•
] to enter the selected tone and exit set mode.
94.8 110.9 131.8
97.4 114.8 136.5
100.0 118.8 141.3
103.5 123.0 146.2
107.2 127.3 151.4
REPEATER OPERATION
] to enter
SET SET MODE
] to enter
SET
156.7 171.3
159.8 173.8
162.2 177.3
165.5 179.9
167.9 183.5
SET MODE
USING
.
SET MODE
SET MODE
USING
F
TX
MR
(unit: Hz)
186.2 203.5 229.1
189.9 206.5 233.6
192.8 210.7 241.8
196.6 218.1 250.3
199.5 225.7 254.1
