Reverse this procedure to install the ExpressCard assembly.

Smart Card reader

Description
Smart Card reader (includes cable)
The Smart Card reader is located under the ExpressCard assembly.
Before removing the Smart Card reader, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the service door (see
6. Remove the optical drive (see
bay hard drive on page
7. Remove the keyboard (see
8. Remove the top cover (see
9. Remove the ExpressCard assembly (see
Remove the Smart Card:
1. Position the computer upright and open as far as possible.
2. Remove the three Phillips PM2.5x4.0 screws (1) that secure the Smart Card reader to the
computer.
3. Lift the Smart Card reader slightly upward and toward the left (2), and then disconnect the cable
from the ZIF connector on the system board (3).
92 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Battery on page 46).
Service door on page
Optical drive on page
59).
Keyboard on page 63).
Top cover on page 72).
ExpressCard assembly on page
48).
57) or upgrade bay hard drive (see
91).
Spare part number
742159-001
Upgrade
