Figure 1-4. Minilibrary Base Module 10-Cartridge Magazine; Figure 1-5. Expansion Unit Rear View - Compaq SW TL881 DLT Mini-Lib/1 Manual
Compaq tl881 minilibrary system users guide (may 1999)
Hide thumbs
Also See for SW TL881 DLT Mini-Lib/1:
- Reference manual (213 pages) ,
- Manual (19 pages) ,
- Manual (18 pages)
Table of Contents
Advertisement
4
Figure 1-4. MiniLibrary Base Module 10-Cartridge Magazine
Slot 0
Front label slide slot
1
5
4
3
Figure 1-5. Expansion Unit Rear View
Pass-Thru Mechanism
motor drive
Power connector
MiniLibrary Base Module robotics interface connectors
1
3
2
Barcode label slide slot (not used)
Slot 9
2
Library robotics SCSI interface
Diagnostics connector
Introduction 1-9
SHR-1226
SHR-1227
