Compaq SW TL881 DLT Mini-Lib/1 Manual page 154

Table 6-2
Fault Symptom Codes
continued
FSC Message
5090 Slave Command Failure
FSC Message
6001 Comm Open Error
6002 Comm Port Send Error
6003 Comm Port Recv Error
6004 EnQ Without IDs
DeQ Without Ids
6005
6006 EnQ Null Pointer
6007 No Free Comm Blks
6010 Pkt Send Error
6011 Pkt Receive Error
Diagnostics and Troubleshooting 6-19
Menu Error Codes – 5xxx
Error occurred sending a menu mode
command to a slave module.
Module Error Codes – 6xxx
An attempt to open the RS-232 serial
communication port used by the inter-
module processes failed.
An inter-module process (Master or
Slave) was sending a packet to a
remote module, but the UART detected
an error condition during the transfer.
An inter-module process (Master or
Slave) was receiving a packet from a
remote module, but the UART detected
an error condition during the transfer.
The Master inter-module process has
repeatedly attempted to send a packet
to a Slave inter-module process, but
all retries have been exhausted before
the packet could be successfully sent.
The Master inter-module process has
repeatedly attempted to receive a
packet from a Slave inter-module
process, but all retries have been
exhausted before the packet could be
successfully received.
Description
Description
continued
