Front Panel HP Procurve Switch
The front panel of the HP ProCurve switch usually has seven types of diagnostic LEDs.
shows these LEDs for a ProCurve 2650. See
LEDs that are on your version of the HP ProCurve switch.
Figure 5-1 HP ProCurve 2650 LEDs
1 3
hp P roCurve
2 4
1 3
Switch 2848
J4904A
Status
Lnk
LED
RPS Act
Power Mode
Fan FDx
Test Spd
Fault
Reset Clear Spd Mode off = 10Mbps
4
2
Item Description
1 Power
2 Fault
3 Self Test
4 Fan Status
5 Port LEDs
74 Ethernet Hardware Troubleshooting
5
6 8 10 12 14 16 18 20 22
5 7 9 1 1 13 15 17 19 21
flash = 100Mbps on = 1000Mbps
6
State Meaning
Green On = The switch is receiving power.
Off = The switch is not receiving power.
Orange On = The switch has encountered a fatal hardware failure or has failed its
self-test.
Off = Indicates that there are no fault conditions on the switch.
Blinking* = A fault has occurred on the switch, one of the switch ports, or
the fan. The status LED for the component with the fault will blink
simultaneously.
Green On = The switch self-test and initialization are in progress after you have
power cycled or reset the switch. The switch is not operational until this
LED goes off.
Off = The switch is not undergoing self-test.
Blinking* = A component of the switch has failed its self-test. The status
LED for that component and the switch Fault LED will blink
simultaneously.
Green On = The cooling fan is working properly.
Off = The cooling fan has failed. The interconnect's Fault LED is blinking
simultaneously.
Green — Displays port link information, network activity information, whether the
overlaid with the port is configured for full-duplex operation, or the speed of the connection
port number depending on the Port LED View selected.
"HP ProCurve Switches" (page 32)
24 26 28 30 32 34 36 38 40
23 25 27 29 31 33 35 37 39
42 44
41 43
M T M T M T M 48
45 46 47 T
Dual Personality Ports 10/100/1000-t(T) or Mini-GBIC(M)
7
Figure 5-1
for the specific
