is delivered to the site, a floor plan and cable routing plan must be completed. For more
information, see the Site Preparation Guide.
Table 2-2 provides an example of the components used in a cluster of 243 application nodes and
13 utility nodes. The application nodes are 2U in height and the control node and utility nodes
are 4U in height. In this configuration, the control node does not have a link to the interconnect.
A total of 19 racks is required to hold all the components.
Table 2-2 Components used in a Cluster of 243 Application Nodes and 13 Utility Nodes
Component
2U Application
node
Node-level
Interconnect
Top-Level
Interconnect
Console Network
Switch
Administration
Network Switch
Interconnect
Management
Network Switch
4U Control Node
Clock boxes
MSA1000
Disk Shelf
4U Utility Node
Total Racks
Figure 2-3 shows how the components are organized in the 14 CBBs, 3 IBBs, UBB, and UXR that
make up the 19 racks of a CP6000 cluster.
26 Platform Core Components
Qty CBB Location UBB Location
and and
Quantity Quantity
243 CBBs (243)
4
2
15 CBBs (14) UBB (1)
15 CBBs (14) UBB (1)
1 UBB
1 UBB
2 UBB
2 UBB
2 UBB (2)
13 UBB (3)
IBB Location UXR Location
and and Quantity
Quantity
NLI IBB (4)
TLI IBB (2)
UXR (10)
Component Rack Count
Total
243 14 CBB
2 IBB
6 1 IBB
16
2
2
2 1 UBB
14 1 UXR
19
