HP Cluster Platform Hardware Kits v2010 Installation Manual
Ac070a cable management bracket installation guide (supersedes generic cable management bracket installation guide)
Hide thumbs
Also See for Cluster Platform Hardware Kits v2010:
- Installation manual (20 pages) ,
- Hardware (4 pages) ,
- Installation manual (16 pages)
Related Manuals for HP Cluster Platform Hardware Kits v2010
Summary of Contents for HP Cluster Platform Hardware Kits v2010
- Page 1 HP Cluster Platform AC070A Cable Management Bracket Installation Guide HP Part Number: AC070A-doc Published: October 2007 Edition: 4.0...
- Page 2 © Copyright 2007 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP...
-
Page 3: Table Of Contents
Table of Contents 1 Preparing for Installation....................6 1.1 Intended Audience..........................6 1.2 Documentation Resources.........................6 1.3 Revision History..........................6 1.4 Kit Description..........................6 1.5 Kit Contents............................7 1.6 Required Resources...........................8 2 Installing the Kit......................9 2.1 Aligning the Bracket..........................9 2.1.1 ProLiant DL380 G5, DL385 G2, and RX2660 Mounting Instructions........9 2.1.2 ProLiant DL585 G1 and ProLiant DL585 G2 Mounting Instructions........10 2.1.3 Installing The Straps........................11 2.2 Securing Cables Using the Straps....................12... - Page 4 List of Figures Bracket.............................7 Fabric Strap............................7 Aligning the Bracket with the PCI Slot of a DL380 G5, DL385 G2, or RX2660 Series Server..9 Aligning the Bracket with the Port of DL 585 Servers (Vertical PCI Slot)........10 Attaching the Strap........................11 Correct Cable and Port Alignment....................12...
-
Page 5: List Of Tables
List of Tables Fastener Specifications........................8... -
Page 6: Preparing For Installation
1 Preparing for Installation This chapter describes what you need to do before you begin installing an AC070A cable management bracket in an HP Rack 10000 Series cabinet. Note that such persons are expected to understand the hazards of working in this environment and to take suitable precautions to minimize danger to themselves and others. -
Page 7: Kit Contents
Note: This bracket is designed to support different types of cables, from 5/16-inch (7.9-mm) minimum diameter to 5/8-inch (15.9-mm) maximum diameter. Refer to the documentation supplied with your cluster before installing the brackets and routing the cables. 1.5 Kit Contents The AC070A cable management kit contains the following components: •... -
Page 8: Required Resources
Table 1-1 Fastener Specifications Qty. Size Format Torque Description 10-32 x .375-inch Phillips 30 in/lb Machine screw, pan-head. For use with a threaded (Posidrive) insert in the server's rail kit, or the 10-32 cage nuts. M6 x 16 mm Phillips 30 in/lb Machine screw, pan-head. -
Page 9: Installing The Kit
2 Installing the Kit At the time of publication, these installation instructions apply to the specific HP servers that are identified in the installation procedures in Section 2.1. This bracket might also be adapted for other cable management uses, as specified in the installation documentation for HP Cluster Platform models. -
Page 10: Proliant Dl585 G1 And Proliant Dl585 G2 Mounting Instructions
The fabric support strap. The strap is attached to the bracket slot with a single cage nut and screw. The cable is routed to the cable management plate, and down to the interconnect. The cable connector (shown in slot 5 in this example for the DL380 G5 and DL385 G2 servers or slot 1 for the RX2660 server), which you must secure level and square to the HCA port to prevent EMI leakage. -
Page 11: Installing The Straps
This position ensures that the center of the cable aligns with the center of the port when you secure the cable with the strap. Adjust the vertical position of the bracket until the two holes in the bracket align with two square holes in the rear rack columns. -
Page 12: Securing Cables Using The Straps
2.2 Securing Cables Using the Straps To secure a cable using the straps, follow these steps: Connect the cable to the port in the PCI adapter and secure it mechanically by its clips, screws, or clamps. Route the cable over the strap, loop the strap through its D-ring, and secure the strap by its hook-and-loop closure. - Page 13 Unstrap the cable and remove its connector from the PCI card port. When disconnecting the cable, ensure that you do not bend it more than the recommended minimum bend radius. The cable specifications are provided in the documentation for your cluster type. Unlock and slide the server all the way out of the rack, as described in the documentation for the server rack kit.
