The TFT5600 is installed in older models of HP Cluster Platform.
Figure 2-25 TFT5600 Rack-Mount Keyboard and Monitor

2.7.3 Console Switch for Cluster Platform

A 4-port USB switch
nodes.
Note:
The 4-port USB console switch is installed in older models of HP Cluster Platform.
Figure 2-26 4-Port USB (KVM) Switch for Cluster Platform

2.7.4 Console Switch for SVA and Cluster Platform

SVA clusters use an 8–port console switch (see
Figure 2-28). The console switch offers single console support, and mounts either behind the
keyboard, or in a rack sidewall to save space in the rack. The console switch has an On-Screen
Display (OSD) interface, which has menus for accessing each attached compute, or serial attached
device. You can identify equipment by a user-defined name, or sequentially by number, enabling
easy access. The single-user server console switch has one input (or user) port for one user console
(one keyboard, monitor, and mouse) and multiple output (or system) ports for connecting multiple
systems to the switch (one-to-many).
52 Platform Core Components
(Figure 2-26) provides up to four outputs to the control node and utility
Figure 2-27) with an expansion module (see
