Magnum 6K32 Managed Switch
1.0

SPECIFICATIONS

1.1

Technical Specifications

Performance
Filtering / Forwarding Rate:
Ethernet:14,880 pps
Fast Ethernet: 148,800 pps
Gigabit Ethernet: 1,488,000 pps
Switching Processing Type: Store and Forward with IEEE 802.3x full-
duplex flow -control, non-blocking
Data Rate: 10Mbps,100Mbps and 1000Mbps
Address Table Capacity: 4K node, self-learning with address aging
Packet buffer size : 240KB for 10/100 and 120KB for 1000Mb
Latency: 5 µs + packet time (100 to 100Mbps)
15 µs + packet time (10 to 10 Mbps, and 10 to 100Mbps)
Network Standards and Compliance
Ethernet V1.0/V2.0 IEEE 802.3: 10BASE-T,
IEEE 802.3u: 100Base-TX, 100BASE-FX
IEEE 802.3z: 1000BASE-X Ethernet(Auto-negotiation)
IEEE 802.3ab: 1000BASE-X Ethernet
IEEE 802.1p: Priority protocol
IEEE 802.1d: Spanning tree protocol
IEEE 802.1w: Rapid Spanning tree protocol
IEEE 802.1q: VLAN Tagging
IEEE 802.3x: Flow Control
IEEE 802.3ad: Link Aggregation (Trunking)
Maximum 10 Mbps Ethernet Segment Lengths
Unshielded twisted pair
Shielded twisted pair
10BASE-FL multi-mode fiber optic
10BASE-FL single-mode fiber optic
Maximum Standard Fast Ethernet Segment Lengths:
10BASE-T (CAT 3, 4, 5 UTP)
100BASE-TX (CAT 5 UTP)
Shielded twisted pair
100BASE-FX, half-duplex, multi-mode
100BASE-FX, full-duplex, multi-mode
100BASE-FX, half-duplex, single-mode
100BASE-FX, full-duplex, single-mode
100BASE-FX, full-duplex, Long Reach
Maximum Standard Gigabit Ethernet Segment Lengths:
1000BASE-T (CAT5E or higher is recommended)
1000BASE-SX, full-duplex, multi-mode(62.5µm cable) - 220m
1000BASE-SX, full-duplex, multi-mode(50µm cable)
1000BASE-LX, full-duplex, single-mode(62.5µm cable) -5Km
www GarrettCom com . .
Installation and User Guide (02/05)
- 100 m (328 ft)
- 150 m (492 ft)
- 2 km (6,562 ft)
- 10 km (32,810 ft)
- 100 m (328 ft)
- 100 m (328 ft)
- 150 m (492 ft)
- 412 m (1350 ft)
- 2.0 km (6,562 ft)
- 412 m (1350 ft)
- 20.0 km (66K32 ft)
- 40.0 km (122K ft)
- 100 m
- 550m
1
