Intelligent Technologies ( IT. ) D77B-DSNAP
Configuration
The only configuration that is necessary for normal operation of the D77B-DSNAP is setting
the MAC ID and baud rate, as described in the "Installation" section, Page 11. However, the
D77B-DSNAP offers a variety of enhanced features. When these features are required, use
the CH Studio software suite or a generic DeviceNet tool to perform the configuration.
This section includes the following configuration procedures, and related instructions and
information:

Using CH Studio

– View D77B-DSNAP General Properties
– Configure Enhanced Features
– Monitor the D77B-DSNAP Status
– Change the I/O Assemblies
Using a generic DeviceNet tool
Using CH Studio
The CH Studio software application is designed for programming and configuring industrial
automation systems. The application simplifies the monitoring and configuration of entire
networks as well as the enhanced features of individual IT. communicating devices within
those networks.
CH Studio takes advantage of the Windows graphical interface to present a suite of tools that
is easy to learn and efficient to use, while meeting the requirements for developing complex
network configurations.
CH Studio performs the following configuration functions for DeviceNet networks:
Discover network devices
Display device properties
Monitor and configure network devices
Save existing network configurations
Configure networks off-line
Configure devices off-line
