Safety

The following safety statements relate to the installation, setup and operation of the Eaton's
Cutler-Hammer IT. D77B-DSNAP and Starter.

Environmental Ratings

The following environmental ratings apply to the D77B-DSNAP.

Table 3: Environmental Ratings

Category
Transportation/
Storage
Operating
Pub. No. MN05004001E
Make sure you read and understand the installation procedures in
this manual before you attempt to set up or operate the equipment.
This instruction manual should be used for proper installation,
setup and operation of the IT. D77B-DSNAP. Improperly installing
and maintaining this product can result in serious personal injury
or property damage. Before attempting installation, setup or
operation, read and understand this entire manual.
Hazardous voltage can cause electric shock and burns. Always
disconnect power before proceeding with any work on this product.
Only apply 24V DC to the Terminal Adapter power terminals. Use
of any other voltage may result in personal injury, property damage
and damage to the IT. D77B-DSNAP.
To provide continued protection against fire or shock hazard, the
complete IT. D77B-DSNAP must be replaced if it becomes
inoperative.
Description
Temperature
Humidity
Temperature
Humidity
Altitude
Shock (IEC 68-2-27)
Vibration (IEC 68-2-6)
Intelligent Technologies ( IT. ) D77B-DSNAP
Notice
WARNING
WARNING
WARNING
WARNING
Specification
-50°C to 80°C [-58°F to 176°F]
5 – 95% non-condensing
0°C to 60°C [32°F to 140°F]
5 – 95% non-condensing
Above 2000 meters [6600 feet] consult factory
15G in any direction for 11 milliseconds
5 – 150 Hz, 5G, 0.7 mm maximum peak-to-peak
3
