September 2002
Physical Features
Physical Description
Figure 1 illustrates the front and back of the IT. D77B-DSNAP and its various features.
Starter
Connector

Dimensions

Figure 2 illustrates the dimensions of the IT. D77B-DSNAP.
Pub. No. MN05004001E
Baud and
MAC ID
Switches
Connector
Breakout
Push Tab
DeviceNet
Status
LED

Figure 1: D77B-DSNAP Features

Figure 2: D77B-DSNAP Dimensions, mm [in]

Intelligent Technologies ( IT. ) D77B-DSNAP
Contactor
Position
Detector
Lock Tab
Feet
5
