September 2002

Product Overview

Description

Cutler-Hammer Intelligent Technologies ( IT. ) D77B-DSNAP ( D eviceNet S tarter N etwork
A dapter P roduct) by Eaton Corporation is the result of a substantive engineering and
marketing effort, involving extensive customer input. This product has greatly increased
functionality of the IT. Electromechanical Starter with the addition of enhanced features. This
front-mount device is a single DeviceNet node providing control and monitoring of an IT.
Electromechanical Starter application.
The D77B-DSNAP provides a communication interface to the following IT. Electromechanical
Starters.

Table 1: D77B-DSNAP Electromechanical Starter Connectivity Table

IEC
E101, FVNR
E501, FVR
B
C
D
E
F

Table 2: D77B-DSNAP S751 Connectivity Table

This manual specifically addresses the DeviceNet Starter Network Adapter Product
(D77B-DSNAP). The D77B-DSNAP provides connectivity to DeviceNet supporting Group 2
slave, I/O poll and explicit messaging.
For further information on the IT. family of devices, visit our Web site at:
www.cutler-hammer.eaton.com/it
Pub. No. MN05004001E
NEMA
N101, FVNR
N501, FVR
00
0
1
2
3
4
5
The D77B-DSNAP can only be applied with the IT. family of starters.
Intelligent Technologies ( IT. ) D77B-DSNAP
Frame
Width
45 mm
54 mm
76 mm
105 mm
140 mm
S751 Soft Start
All
Notice
1
