Table 35: Soft Start Object 0x2D — Instance 1
Attribute Access Data Type Name
3
4
5
7
16
100
101
38
Get BOOL AtReference
Get USINT StartMode
Get USINT StopMode
Get UINT RampTime1
Get UINT DecelTime
Get USINT Start Torque
Get WORD Status Bits
Value
Starting/stopping output voltage
reference status
0 = Not At Reference
1 = Output At Voltage Reference
1 = Voltage Ramp
No Current Limit
The DSNAP will always return the value 1
when accessing this attribute.
1 = Ramp Down
The DSNAP will always return the value 1
when accessing this attruibute.
Tenths of Seconds
Tenths of Seconds
Starting Torque Pot reading
Status bits
