Canon imagePROGRAF iPF9400S Basic Manual page 79

iPF9400S
4
Grasp the Belt, insert it between the Belt Stopper,
and affix the Belt Stopper with a hex screw at the
position indicated.
•
Here, the Belt Stopper is the one that was removed and stored after initial installation. Neglecting to attach
the Belt Stopper may damage the printer.
Important
• Do not touch the Linear Scale (a), Carriage Shaft
(b), or Fixed Blade (c). This may stain your
hands and damage the printer.
5
Close the Top Cover.
6
Tape down printer covers to secure them, in the reverse order of tape removal during installation.
7
If the Output Stacker is installed, reverse the installation procedure to remove the Output Stacker.
Basic Guide
Preparing to Transfer the Printer
79
