iPF9400S
•
When handling the Printhead, always hold it by the grips (a). Never touch the nozzles (b) or metal contacts
(c). This may damage the Printhead and affect printing quality.
Important
Never touch the ink supply section (d). This may
•
cause printing problems.
9
While firmly holding the Printhead you have re-
moved, use your other hand to remove the orange
Protective Part (a). Squeeze the grips (c) of Protec-
tive Part (b) and pull it down to remove it.
•
The inside surface of the Protective Part (a) and Protective Part (b) is coated with ink to protect the nozzles.
Be careful not to touch these surfaces when removing the caps.
Important
•
The Printhead contains ink to protect the nozzles. We recommend removing Protective Part (b) as you hold it
over the Printhead package or safely out of the way to avoid spilling ink and staining your clothes or the sur-
rounding area. If ink accidentally spills, wipe off the ink with a dry cloth.
•
If you need to put a Printhead somewhere temporarily before installation, do not keep the nozzles and metal
contacts facing down. If the nozzles or metal contacts are damaged, it may affect the printing quality.
•
Do not reattach the Protective Part or protective material. Dispose of these materials in accordance with local
regulations.
10
With the nozzles facing down and the metal con-
tacts toward the back, tilt the Printhead slightly for-
ward and insert it into the Carriage. Carefully push
the printhead firmly into the Carriage, ensuring that
the nozzles and metal contacts do not touch the
carriage.
Basic Guide
Replacing the Printhead
