Top Cover (Inside)
a Carrying Handles
When carrying the printer, have six people hold it by these handles under both sides.
b Media Take-up Unit Power Inlet
Connect the power cord of the Media Take-up Unit here.
c Ethernet Port
Connect an Ethernet cable to this port.
d USB Port
Connect a USB cable to this port. It supports Hi-Speed USB.
e Manual Pocket
Store printer manuals in this pocket.
f Power Supply Connector
Connect the power cord to this connector.
Top Cover (Inside) Top Cover (Inside)
a Top Cover Roller
Prevents paper from rising when ejected.
b Paper Alignment Line
70
Align paper with this line when loading it.
