Maintenance >

Printheads

Printheads
Printhead ......................................................................................................................................................... 728

Checking for Nozzle Clogging ......................................................................................................................... 728

Cleaning the Printhead .................................................................................................................................... 729
Replacing the Printhead .................................................................................................................................. 730
Printhead
A replacement Printhead.
• Printhead PF-04
Note
• For instructions on replacing the Printhead, see "Replacing the Printhead."
Checking for Nozzle Clogging
10
If printing is faint or affected by banding in different colors, make sure the Printhead nozzles are clear by printing a test
pattern to check the nozzles.
Note
• Nozzles are periodically checked to ensure they are clear. Configure the settings on the Control Panel menu
in Nozzle Check. (See "Menu Settings.")
1.
Load unused paper.
• Attaching the Roll Holder to Rolls
• Loading Rolls in the Printer
• Loading Sheets in the Printer
728
2.
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to select the Settings/Adj. tab (
Printhead
>
→P.568
→P.572
→P.594
→P.656
→P.730
).
iPF650
