Loading Rolls In The Printer - Canon imagePROGRAF iPF650 User Manual

Handling Paper >

Loading Rolls in the Printer

Follow these steps to load rolls in the printer.
Note
• Before loading rolls, make sure the printer is clean inside the Top Cover and around the Ejection Guide. If
these areas are dirty, we recommend cleaning them in advance. (See "Cleaning Inside the Top Cover.")
→P.744
1.
Press the Load button.
2.
Press ▲ or ▼ to select Load Roll Paper, and then press the OK button.
6
3.
Positioning your hands as shown, open the Roll Cover.
572
Loading Rolls in the Printer
Handling rolls >
Note
• If any paper has been advanced that will not be used, a message is shown requesting you to remove it.
Press ▲ or ▼ to select "Yes", and then press the OK button. Remove the paper and go to the next
step.
iPF650
