TMS320C6201 Silicon Errata
Advisory 2.0.13
Revision(s) Affected:
Details:
Advisory 2.0.14
Revision(s) Affected:
Details:
Workaround:
Advisory 2.0.18
Revision(s) Affected:
Details:
Workaround:
2.0
XEMPTY goes low and stays low when DXR was written on either the last bit or next-to-last bit
of the previous word being transferred to DX. (Internal Reference Number 3383)
EMIF: Multiple SDRAM CE Spaces: Invalid Access After Refresh
2.0
This bug exists only in those systems that have SDRAMs in more than one CE space. When
there are two SDRAM accesses performed to two CE spaces, followed by a refresh, the pages
in all CE spaces with SDRAM are deactivated. The first CE space to be accessed after the
refresh is activated correctly. The bug is that if the second CE space is accessed on the same
page as before the refresh, it will not be activated before the read or write is attempted.
(Internal Reference Number 3952)
Avoid use of multiple CE spaces of SDRAM within a single refresh period.
2.0
This bug occurs when the CPU has high priority and is accessing a bank with word access
(load or store) followed by similar (load or store) half-word access, and the DMA is also
accessing the same bank simultaneously with word accesses:
Example:
LDW
.D1
LDW
.D2
|
The data transfer done by the DMA is corrupted in half-words (or rather not updated) when the
DMA transfer is complete. (Internal Reference Number 4195)
When DMAing to/from internal memory with DMA in low priority, use half-word or byte element
size transfers. Alternatively, avoid the above code sequence during DMA transfers.
McBSP: XEMPTY Stays Low When DXR Written Late
DMA/Internal Data Memory: Conflict Data Corruption
*A3, A4
*A3, A5 ; A DMA to the bank containing never completes
; but the DMA continues as if it did
SPRZ153
27
