Embedded Fonts

The 428M printer provides seven resident Helvetica style 203 DPI embedded fonts that are
selected using the CGN when text is selected by the appropriate TCI value.
CGN POINT
VALUE SIZE
1 6
2 8
3 10
4 12
5 14
7 12
8 12
4.6.6.2

Downloadable Fonts and Graphics

When selecting downloadable fonts and graphics using TCI value of "7" or "8", the CGN
denotes the memory slot (1-255) where the font or graphic has been stored. See Chapters
6 and 7 for additional information regarding downloadable fonts and graphics.
For example: If a graphic had been stored into RAM (volatile) memory slot 1 (see Chapter 5
for additional information), the proper TCI would be "8" and the CGN value would be "1".
The Model 428M also provides a standard downloadable font set containing 19 Helvetica
style fonts. These fonts are stored in the printer's non-volatile flash memory and are
accessed with a TCI of 7 and the appropriate CGN value. Custom font sets may be loaded
into printers at the factory, ask your Microcom Representative for additional information on
custom font sets.
Downloadable fonts must be stored in two separate directions; 0 and 90 degrees. This
means that the 0 degree fonts should be used with 0 and 180 degree rotations while the 90
degree fonts used with 90 and 270 degree rotations in order to achieve correct printing.
CGN POINT
VALUE SIZE
10 6
11 6
12 8
13 8
14 10
15 10
4-14
Embedded Bitmapped Fonts
FONT TYPE
Swiss™721 Bold
Swiss™721 Normal
Swiss™721 Normal
Swiss™721 Normal
Swiss™721 Normal
OCR-A
OCR-B
Table 4-4 CGN—Embedded Fonts
Standard Downloadable Font Set
Swiss™721 Normal 0 degree
Swiss™721 Normal 90 degree
Swiss™721 Normal 0 degree
Swiss™721 Normal 90 degree
Swiss™721 Normal 0 degree
Swiss™721 Normal 90 degree
FONT SAMPLE
6pt ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890
8pt ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890
10pt ABCDEFGHIJKLMNOPQRSTUVWXYZ
12pt ABCDEFGHIJKLMNOPQRSTU
14pt ABCDEFGHIJKLMNOPQR
ABCDEFGHIJKLMNOPQRSTUVWXYZ
ABCDEFGHIJKLMNOPQRSTUVWXYZ
FONT TYPE
