Bar Codes
AI
410 Ship To (Deliver To) Location Code Using EAN-13
411 Bill To (Invoice To) Location Code Using EAN-13
Purchase From (Location Code of Party from Whom
412
414
Ship To (Deliver To) Postal Code Within a Single
420
Ship To (Deliver To) Postal Code with 3 Digit ISO
421
8001
8002
UPC/EAN Number and Serial Number of Returnable
8003
Coupon Extended Code – Number System Character
8100
Coupon Extended Code – Number System Character ,
8101
Coupon Extended Code – Number System Character
8102
Mutually Agreed, Between Trading Partners or FACT
90
91
92
93
94
95
96
97
98
99
Each subfield's format is expressed as the format of the Application Identifier number + the
format of the associated data. Each subfield must adhere to the format specified or else the
printer will be unable to locate following subfields, causing errors generating the bar code.
Any variable length subfield, unless it is the last subfield in the field, must be terminated by
the two characters "#6" (pound+6). These characters are translated as the Code 128
"FNC1" character, which is specified by the UCC/EAN 128 symbologies variable-length field
terminator. The characters "#6" are only used internally and are not printed.
8-14
Content
Goods are Purchased)
EAN Location Code for Physical Identification
Postal Authority
Country Code Prefix
Roll Products – Width Length, Core Diameter,
Direction, and Splices
Electronic Serial Number for Cellular Mobile
Telephones
Asset
and Offer
Offer, and End of Offer
preceded by zero
Intra-Company (Internal)
Intra-Company (Internal)
Intra-Company (Internal)
Intra-Company (Internal)
Internal-Carriers
Internal-Carriers
Intra-Company (Internal)
Intra-Company (Internal)
Internal
Table 8-5 UCC/EAN Application Identifiers
