1–3c: High Damp
H. D (High Damp)
Specifies the amount of attenuation that will be
applied to the high-frequency component of the
feedback signal within the comb filter.
As this value is increased, the tone will become more
mellow. Conversely, decreasing this value will
produce a brighter tone.
AMS (Alternate Modulation Source)
Selects a modulation source ( p.48 of this manual)
that will control "H. D."
Intensity (High Damp AMS Intensity)
Specify the depth and direction in which "AMS" will
affect high damp.
18
VPM
The output of a carrier is phase-modulated by a
[0...99]
modulator, and output through wave shape processing.
By controlling the wave shaping parameters and the
feedback gain, tonal changes that are different than
simple phase modulation can be produced.
[Off...MIDI:CC#83]
[–99...+99]
1–3a: Carrier
Wave
Selects the carrier waveform.
Level
Specifies the output level of the carrier. This will
determine the output level of the VPM oscillator.
AMS1 (Alternate Modulation 1 Source)
Selects a modulation source 1 ( p.48 of this manual)
that will control "Level."
Intensity (Level AMS1 Intensity)
Specifies the depth and direction of the effect of "AMS1."
AMS2 (Alternate Modulation 2 Source)
Selects a modulation source 2 ( p.48 of this manual)
that will control "Level."
Intensity (Level AMS2 Intensity)
Specifies the depth and direction of the effect of "AMS2."
Wave Shape
Specifies the number of cycle of wave shaping.
As this value is increased, the number of cycles will
increase, causing more overtones to be added to the
high-frequency range of the sound.
Carrier Pitch
(Basic Pitch)
Modulator Pitch
Modulator Level
Modulator
Carrier
1–3a
1–3b
[Saw, Square, Triangle, Sine]
Wave Shape Parameter
Carrier Level
Wave
Output
Shape
Feedback Gain
[0...99]
[Off...MIDI:CC#83]
[–99...+99]
[Off...MIDI:CC#83]
[–99...+99]
[0...99]
