Control change transmission/
reception for the EXB-MOSS
In the same way as bank A–E or G programs, bank F
programs can receive MIDI control changes CC#70–
79, and can be operated by the front panel realtime
control knobs 1–4 in A-mode. In B-mode, CC#70–79
can be assigned as knob functions, and used to control
the program sound. These settings can be saved by
writing them in Program mode.
Refer to p.223 of the TRITON Parameter Guide.
CC#70: Sustain Level
"Sustain Level" (Program P4: AmpEG tab, Program P6)
This controls the EG that is selected by Filter
EG (Program P3: Filter 1/2 tab) and Amp
Level EG (Program P4: Amp 1/2 Level tab).
CC#71: Filter Resonance Level
"Filter A Resonance" (Program P3: Filter 1/2 tab)
"Filter B Resonance" (Program P3: Filter 1/2 tab)
CC#72: Release Time
"Release Time" (Program P4: AmpEG tab, Program P6)
This controls the EG that is selected by Filter
EG (Program P3: Filter 1/2 tab) and Amp
Level EG (Program P4: Amp 1/2 Level tab).
CC#73: Attack Time
"Attack Time" (Program P4: AmpEG tab, Program P6)
"Time Modulation At" (Program P4: AmpEG tab,
Program P6)
This controls the EG that is selected by Filter
EG (Program P3: Filter 1/2 tab) and Amp
Level EG (Program P4: Amp 1/2 Level tab).
CC#74: Low Pass Filter Cutoff Frequency
"Filter A Frequency" (Program P3: Filter 1/2 tab)
"Filter B Frequency" (Program P3: Filter 1/2 tab)
CC#75: Decay Time
"Decay Time" (Program P4: AmpEG tab, Program
P6: EG1–4 tabs)
"Slope Time" (Program P4: AmpEG tab, Program P6:
EG1–4 tabs)
This controls the EG that is selected by Filter
EG (Program P3: Filter 1/2 tab) and Amp
Level EG (Program P4: Amp 1/2 Level tab).
10
CC#76: Pitch LFO Speed
"LFO1–4 Frequency" (Program P5: LFO1–4 tabs)
If LFO 1–4 is selected for Pitch Modulation
AMS1, AMS2 (Program P2: OSC1/2 Pitch
Mod. tab) or Common Pitch Modulation AMS
(Program P2: Common Pitch Mod. tab), this
control change message will control that LFO.
CC#77: Pitch LFO Intensity
"Pitch Modulation AMS1 Intensity" (Program P2:
OSC1/2 Pitch Mod. tab)
"Pitch Modulation AMS2 Intensity" (Program P2:
OSC1/2 Pitch Mod. tab)
"Common Pitch Modulation AMS Intensity" (Pro-
gram P2: Common Pitch Mod. tab)
If LFO 1–4 is selected for the corresponding
AMS, this control change message will control
that LFO.
CC#78: Pitch LFO Delay
"LFO1, 2, 3, 4 Fade" (Program P5)
If LFO 1–4 is selected for Pitch Modulation
AMS1, AMS2 (Program P2: OSC1/2 Pitch
Mod. tab) or Common Pitch Modulation AMS
(Program P2: Common Pitch Mod. tab), this
control change message will control that LFO.
CC#79: Filter EG Intensity
"Filter A EG Intensity" (Program P3: Filter 1/2 tab)
"Filter B EG Intensity" (Program P3: Filter 1/2 tab)
