Continued, reliable operation of the radar depends on how you care for it. The simple maintenance tips that follow
can help you save time and money, and avoid premature equipment failure.

■ Periodic maintenance

WARNING! BE SURE
R
is OFF before performing any maintenance.

■ Scanner unit maintenance

WARNING! BE SURE
R
is OFF whenever you are working with the scanner
unit.

■ Display unit maintenance

WARNING! BE SURE
R
fore working on the radar.

■ Options

• OPC-1077A SYSTEM CABLE (for only MR-1200RII)
Allows you to install the display unit and scanner up to 20 m (65.6 ft) apart.
• OPC-1078A SYSTEM CABLE
Allows you to install the display unit and scanner up to 30 m (98.4 ft) apart.
[POWER]/[ ]
[POWER]/[ ]
the power is OFF be-

MAINTENANCE

q Keep the equipment as clean as possible.
• Use a soft cloth to remove dirt, dust and water.
w Check all hardware for loose screws, bolts, etc.
e Check cables and terminal connections.
D Cleaning
q Wipe the surface of the scanner with a clean soft
cloth.
• DO NOT use harsh solvents such as benzine or alco-
hol.
w Check that there is no dirt or caked-on salt.
• A heavy deposit of dirt or caked-on salt on the painted
surface of the upper scanner unit will cause a consider-
able drop in radar performance.
e Check for cracks or deterioration of the rubber pack-
ing and replace it if necessary.
D Painting (MR-1200TII/TIII)
To prevent the corrosion, paint the surface of the
scanner body (except the antenna unit) twice a year
or more.
D Mounting
Check the mounting bolts of the scanner unit and
tighten if necessary.
D Cleaning
Dirt on the LCD will, in time, leave a film of contami-
nates which tend to dim the picture.
q Wipe the surface of the display unit with a clean soft
cloth.
• DO NOT use strong solvents such as benzene or alco-
hol.
w If the picture is still dim, clean the LCD screen.
