ERROR MESSAGE

■ Error message list

Message
BRG INPUT FAIL*
TRIG SIGNAL FAIL*
SHM SIGNAL FAIL*
POSN INPUT FAIL*
CHECK SCANNER CONNECTION*
* 1 Push any key to cancel the error message and beep tone. Turn OFF the power, then check the external data
cable connection.
2
* An electricity failure may occur, turn OFF the power, then consult your dealer or service person.
3
* Push any key to cancel the error message and beep tone.
* 4 Turn OFF the power, then check the system cable connections.

■ AIS error message list

An error message is displayed when a system error is received from the AIS unit.
See the AIS unit instructions for details.
(Some examples)
AIS: TX MALFUNCTION
AIS: ANTENNA VSWR EXCEEDS LIMIT
AIS: RX CHANNEL 1 MALFUNCTION
AIS: RX CHANNEL 2 MALFUNCTION
AIS: RX CHANNEL 70 MALFUNCTION
AIS: GENERAL FAILURE
AIS: MKD CONNECTION LOST
AIS: EXTERNAL EPFS LOST
AIS: NO SENSOR POSITION IN USE
AIS: NO VALID SOG INFORMATION
AIS: NO VALID COG INFORMATION
AIS: HEADING LOST/INVALID
AIS: NO VALID ROT INFORMATION
Only the first 29 digits of the error message are displayed. If the message is longer than 30 digits, "..." is displayed
after the 29th digit.
39
1 • The Azimuth signal is interrupted. An alarm sounds within 5 seconds and
the display reverts to H UP mode in approximately 1 minute.
1
• If the TRIGGER signal is interrupted for more than 15 seconds, an
alarm sounds.
2 • If the SHM signal is interrupted for more than 15 seconds, an alarm
sounds.
1
• If the position signal is interrupted for more than 15 seconds, an
alarm sounds.
4 • The system cable may not be properly connected.
Message contents
Condition
