SPECIFICATIONS

D D General
• Frequency coverage
U.S.A. VHF
UHF
Asia
VHF
UHF
Europe, Europe-1, UK, France
VHF
UHF
Italy
VHF
UHF
• Mode
• Frequency stability
• Tuning steps
• Antenna connector
• Usable battery pack/case : See options on page at right
• External DC power
• Current drain
(at 13.5 V DC typical)
Transmit at 5 W
at 0.5 W
Receive rated audio 210 mA
power saved 40 mA
• Usable temperature range : –10˚C to +60˚C; +14˚F to +140˚F
• Dimensions
(with BP-173/180; projections not included)
• Weight
(with BP-173 and antenna)
42
:
Tx: 144–148 MHz Rx: 118–174 MHz*
Tx: 440–450 MHz Rx: 400–470 MHz*
Tx: 144–148 MHz Rx: 118–174 MHz*
Tx/Rx: 430–440 MHz
Tx/Rx: 144–146 MHz
Tx/Rx: 430–440 MHz
Tx/Rx: 144–146 MHz
Tx/Rx: 430–434/435–438 MHz
1
Guaranteed ranges are: * 144–148; *
: FM, AM
(Rx for 118–136 MHz; USA and
Asia versions only)
: ±5 ppm
(0˚C to +50˚C; +32˚F to +122˚F)
: 5, 10, 12.5, 15, 20, 25, 30 or 50 kHz
(50 Ω)
: BNC
: 4.5 to 16 V DC
(negative ground)
:
1.6 A /1.5 A
(VHF) (UHF)
500 mA /600 mA
(VHF) (UHF)
(average)
57(W)×137(H)×33(D) mm
1 13 5
; 2 ⁄ (W)×5 ⁄ (H)×1 ⁄ (D) in
4 32 16
: 450 g; 1 lb
D D Transmitter
• Output power †
1 (at 13.5 V DC)
• Modulation system
2
• Max. frequency deviation
1
• External microphone jack : 3-conductor 2.5 mm (
D D Receiver
• Receive system
• Intermediate frequencies :
VHF
2
440–450
UHF
• Sensitivity †
(12 dB SINAD)
• Squelch sensitivity
• Selectivity
• Spurious and image rejection ratio
VHF
UHF
• Audio output power
• External speaker jack
† Specifications guaranteed at a transceiver temperature of +25°C (+77°F).
All stated specifications are subject to change without notice or obligation.
: 5 W or 0.5 W selectable
(for both VHF and UHF)
: Variable reactance frequency modulation
† : ±5.0 kHz
1
⁄
10
: Double conversion superheterodyne
1st 30.85 MHz 2nd 450 kHz
1st 46.05 MHz 2nd 450 kHz
: Less than 0.16 µV
(original band)
Less than 0.32 µV
(opposite band)
: Less than 0.16 µV
: More than 15 kHz/–6 dB
Less than 30 kHz/–60 dB
† :
More than 60 dB
More than 50 dB
1
*Except for ⁄ of IF and 2nd image frequencies
2
† :
(at 13.5 V DC)
More than 180 mW
at 10% distortion with
an 8 Ω load
1
: 3-conductor 3.5 mm ( ⁄
8
")/2 kΩ
")/8 Ω
