Interface (Ports & Jacks)

Ports and Jacks

Item

Card Reader

DC-In Jack

DVI-Out Port

A

e-SATA/USB Port

e-SATA
/
A - 2 Interface (Ports & Jacks)
The card reader allows you to use the following digital storage cards:
MMC (MultiMedia Card)
SD (Secure Digital)
MS (Memory Stick)
MS (Memory Stick Pro)
Plug the supplied AC/DC adapter into this jack to power your computer.
The DVI-Out (Digital Visual Interface) Port is a video connector interface. This allows you to
connect an external monitor, TV or Flat Panel Display etc. as a display device (see
Other Displays" on page B -
monitor you will need to use a converter to convert the signal from DVI to VGA.
This is a combined e-SATA (external Serial Advanced Technology Attachment)/ USB 2.0
compatible port.
Plug external Serial ATA hard drives into this e-SATA (external Serial Advanced Technology
Attachment) port. See "USB 2.0/1.1 Ports" on page A - 4
Not: The eSATA port only supports hot-swapping if you have selected AHCI mode in SATA Mode
Selection in the BIOS (see "SATA Mode & eSata Port" on page 5 -
mode, then hot-swapping devices connected to the eSATA port is not supported.
Note that hot-swapping is NOT supported in the Windows XP O/S.
Description
RS MMC (requires PC adapter)
Mini SD (requires PC adapter)
MS Duo (requires PC adapter)
5) by means of a DVI cable. If you are using an older type of
for USB port information.
"Attaching
8). If you have selected IDE
